Regulated Single & Dual Output
2:1 Input Range
Compact DIP8 Package
1500 VDC Isolation
Operating Temperature -40 °C to +95 °C
ITE Safety Approvals
Full Load at 70 °C
Class A Conducted & Radiated Emissions
3 Year Warranty
IEU0248D12 XP Power DC/DC Converter 2watt Vin: 36-75Vdc Vout: ±12Vdc Iout: ±0,083A
IEU0248D12
Features:
Regulated Single & Dual Output
2:1 Input Range
Compact DIP8 Package
1500 VDC Isolation
Operating Temperature -40 °C to +95 °C
ITE Safety Approvals
Full Load at 70 °C
Class A Conducted & Radiated Emissions
3 Year Warranty
IEU0248D12 XP Power DC/DC Converter 2watt Vin: 36-75Vdc Vout: ±12Vdc Iout: ±0,083A IEC60950-1, UL/cUL60950-1, UL/cUL62368-1, EN55022 Class A
IEU0248D12
Data sheet
- Applications
- Industrial Automation
- POWER
- 2watt
- VOLTAGE OUT
- ±12Vdc
- CURRENT
- ±0,083A
- VOLTAGE IN
- 36-75Vdc
- NUMBER OF OUTPUTS
- 2
- CASE
- DIP
- PROTECTION LEVEL
- no IP
- WEIGHT (kg)
- 0,0039
- LENGTH (cm)
- 1,4
- WIDTH (cm)
- 1,4
- HEIGHT (cm)
- 0,8
- MANUFACTURER CODE
- IEU0248D12
