Single unregulated output
±10% input range SIP7 package
SMD DIP8 package
1.5kVDC isolation, 3kVDC option
Industry standard pinout
UL62368-1 safety approvals
Continuous short circuit protection
Tape & reel package available
Operating temperature -40°C to +105°C
Full load to 100°C
3 year warranty
IES0105S06 XP Power DC/DC Converter 1watt Vin: 4,5-5,5Vdc Vout: 6Vdc Iout: 0,167A
IES0105S06
Features:
Single unregulated output
±10% input range SIP7 package
SMD DIP8 package
1.5kVDC isolation, 3kVDC option
Industry standard pinout
UL62368-1 safety approvals
Continuous short circuit protection
Tape & reel package available
Operating temperature -40°C to +105°C
Full load to 100°C
3 year warranty
IES0105S06 XP Power DC/DC Converter 1watt Vin: 4,5-5,5Vdc Vout: 6Vdc Iout: 0,167A UL62368-1
IES0105S06
Data sheet
- Applications
- Industrial Automation
- POWER
- 1watt
- VOLTAGE OUT
- 6Vdc
- CURRENT
- 0,167A
- VOLTAGE IN
- 4,5-5,5Vdc
- NUMBER OF OUTPUTS
- 1
- CASE
- SMD
- PROTECTION LEVEL
- no IP
- WEIGHT (kg)
- 0,0014
- LENGTH (cm)
- 1,32
- WIDTH (cm)
- 0,85
- HEIGHT (cm)
- 0,725
- MANUFACTURER CODE
- IES0105S06
