Medical and Industrial IT Approvals EN60601 and EN 62368-1
Wide 4:1 Input Range
Compact 2” x 1” Industry Package
Temperature range -40 °C a +105 °C
Full load up to 73 °C Ambient temperature
5000 VAC insulation, 2 x MOPP ; 250 VAC
2.5 µA current leakage
5 years warranty
TDK-Lambda PXD-M30-48WS24 Medical DC/DC Converter 30watt 24Vdc 1,25A
PXD-M30-48WS24
Features:
Medical and Industrial IT Approvals EN60601 and EN 62368-1
Wide 4:1 Input Range
Compact 2” x 1” Industry Package
Temperature range -40 °C a +105 °C
Full load up to 73 °C Ambient temperature
5000 VAC insulation, 2 x MOPP ; 250 VAC
2.5 µA current leakage
5 years warranty
TDK-Lambda PXD-M30-48WS24 Medical DC/DC Converter 30watt 24Vdc 1,25A
PXD-M30-48WS24
Data sheet
- Applications
- Medical
- POWER
- 30watt
- VOLTAGE OUT
- 24Vdc
- CURRENT
- 1,25A
- VOLTAGE IN
- 18-75Vdc
- NUMBER OF OUTPUTS
- 1
- CASE
- DIP
- PROTECTION LEVEL
- no IP
- WEIGHT (kg)
- 0,032
- LENGTH (cm)
- 5,08
- WIDTH (cm)
- 2,54
- HEIGHT (cm)
- 1,02
- MANUFACTURER CODE
- PXD-M30-48WS24
