Medical Approvals EN60601
Wide range input
Pin Out DIP24
Temperature range -40 °C a +105 °C
Full load up to 77 °C Ambient temperature
5000 VAC insulation, 2 x MOPP ; 250 VAC
2.5 µA current leakage
MTBF 384.900 hrs
5 years warranty
TDK-Lambda PXC-M06-24WS3P3 Medical DC/DC Converter 5,9watt 3,3Vdc 1,8A
PXC-M06-24WS3P3
Features:
Medical Approvals EN60601
Wide range input
Pin Out DIP24
Temperature range -40 °C a +105 °C
Full load up to 77 °C Ambient temperature
5000 VAC insulation, 2 x MOPP ; 250 VAC
2.5 µA current leakage
MTBF 384.900 hrs
5 years warranty
TDK-Lambda PXC-M06-24WS3P3 Medical DC/DC Converter 5,9watt 3,3Vdc 1,8A
PXC-M06-24WS3P3
Data sheet
- Applications
- Medical
- POWER
- 5,9watt
- VOLTAGE OUT
- 3,3Vdc
- CURRENT
- 1,8A
- VOLTAGE IN
- 9-36Vdc
- NUMBER OF OUTPUTS
- 1
- CASE
- DIP
- PROTECTION LEVEL
- no IP
- WEIGHT (kg)
- 0,014
- LENGTH (cm)
- 3,18
- WIDTH (cm)
- 2,03
- HEIGHT (cm)
- 1,02
- MANUFACTURER CODE
- PXC-M06-24WS3P3
