Medical Approvals EN60601
Wide range input
Pin Out DIP24
Temperature range -40 °C a +105 °C
Full load up to 77 °C Ambient temperature
5000 VAC insulation, 2 x MOPP ; 250 VAC
2.5 µA current leakage
MTBF 384.900 hrs
5 years warranty
TDK-Lambda PXC-M06-48WD05 Medical DC/DC Converter 6watt 5Vdc; -5Vdc 0,6A; -0,6A
PXC-M06-48WD05
Features:
Medical Approvals EN60601
Wide range input
Pin Out DIP24
Temperature range -40 °C a +105 °C
Full load up to 77 °C Ambient temperature
5000 VAC insulation, 2 x MOPP ; 250 VAC
2.5 µA current leakage
MTBF 384.900 hrs
5 years warranty
TDK-Lambda PXC-M06-48WD05 Medical DC/DC Converter 6watt 5Vdc; -5Vdc 0,6A; -0,6A
PXC-M06-48WD05
Data sheet
- Applications
- Medical
- POWER
- 6watt
- VOLTAGE OUT
- -5Vdc
5Vdc - CURRENT
- -0,6A
0,6A - VOLTAGE IN
- 18-75Vdc
- NUMBER OF OUTPUTS
- 2
- CASE
- DIP
- PROTECTION LEVEL
- no IP
- WEIGHT (kg)
- 0,014
- LENGTH (cm)
- 3,18
- WIDTH (cm)
- 2,03
- HEIGHT (cm)
- 1,02
- MANUFACTURER CODE
- PXC-M06-48WD05
