HRL3024S2K0N XP Power High Voltage DC-DC input 22 to 30Vdc output 0 to -2000V

HRL3024S2K0N

Datasheet Download

Features:

High Voltage DC-DC Converters

+24VDC Input [22 to 30V]

Output Voltage & Current Regulated

0 to 100% Programmable Output & Current

Voltage & Current Monitor Outputs

Operating Temperature: -40°C to +70°C

Short Circuit, Arc, and Overload Protections

On-board +5V Reference

Efficiency >80%

Low Ripple <0.05%

Premier Thermal Performance

3 Year Warranty

Regulated high voltage DC-DC converter, 0 to 100% programmable output 0 to -2000V and current with output 0 to -2000V voltages of 0 to -2000VDC - IEC/UL/CSA/EN62368, CE Directive, RoHs, LVD, RoHs 2 and 3 directive (2011/65/EU)
HRL3024S2K0N

Data sheet

Applications
Laboratory
POWER
30watt
VOLTAGE OUT
0 to -2000V
CURRENT
15mA
VOLTAGE IN
22 to 30Vdc
NUMBER OF OUTPUTS
1
CASE
Baseplate-cooled
WEIGHT (kg)
0,12
LENGTH (cm)
7,62
WIDTH (cm)
3,81
HEIGHT (cm)
1,86
MANUFACTURER CODE
HRL3024S2K0N
New
