High Voltage DC-DC Converters
+24VDC Input [22 to 30V]
Output Voltage & Current Regulated
0 to 100% Programmable Output & Current
Voltage & Current Monitor Outputs
Operating Temperature: -40°C to +70°C
Short Circuit, Arc, and Overload Protections
On-board +5V Reference
Efficiency >80%
Low Ripple <0.05%
Premier Thermal Performance
3 Year Warranty
HRL3024S1K5P XP Power High Voltage DC-DC input 22 to 30Vdc output 0 to +1500V
HRL3024S1K5P
Features:
High Voltage DC-DC Converters
+24VDC Input [22 to 30V]
Output Voltage & Current Regulated
0 to 100% Programmable Output & Current
Voltage & Current Monitor Outputs
Operating Temperature: -40°C to +70°C
Short Circuit, Arc, and Overload Protections
On-board +5V Reference
Efficiency >80%
Low Ripple <0.05%
Premier Thermal Performance
3 Year Warranty
Regulated high voltage DC-DC converter, 0 to 100% programmable output 0 to +1500V and current with output 0 to +1500V voltages of 0 to +1500VDC - IEC/UL/CSA/EN62368, CE Directive, RoHs, LVD, RoHs 2 and 3 directive (2011/65/EU)
HRL3024S1K5P
Data sheet
- Applications
- Laboratory
- POWER
- 30watt
- VOLTAGE OUT
- 0 to +1500V
- CURRENT
- 20mA
- VOLTAGE IN
- 22 to 30Vdc
- NUMBER OF OUTPUTS
- 1
- CASE
- Baseplate-cooled
- WEIGHT (kg)
- 0,12
- LENGTH (cm)
- 7,62
- WIDTH (cm)
- 3,81
- HEIGHT (cm)
- 1,86
- MANUFACTURER CODE
- HRL3024S1K5P
